进入新城新的行业，找以前同事的邮箱，发现有以前公司转发自己邮箱学习资料的资料。希望能帮助需要帮助的朋友们。谢谢你的关心。

Backlight:背光。

CCFL(CCFT)(COLD CATODE FLUORESCENT LIGHT/TUBE):冷阴极荧光灯。

复合视频复合视频。

Component vide分量视频。

板载芯片(COB): IC裸片作为国情固定在印刷电路板上。

COF(Chip On Film):将IC封装在柔性电路板中。

COG(Chip On Glass):将IC封装在玻璃中。

阴极射线管(CRT):阴极射线管。

每英寸点数(DPI):点。

占空比：占空比，高于明亮阈值电压的部分在一个周期内所占的比例。

数位视觉介面(DVI):(VGA)数位连接器。

电子控制参考(ECB):电子控制双折射。

电子发光(EL):电致发光。EL层由高分子量薄片组成。

FSTN(Formulated STN):胶片校正STN，用于黑白显示器。

高扭曲向列(HTN):高扭曲方向列的显示类型。

集成电路(IC):集成电路。

Inverter:反相器。

IDIUM-TIN OXIDE :氧化铟锡。

液晶显示器(LCD):液晶显示器。

Liquid Crystal Module(LCM):平面显示器模组。

发光二极管(LED):发光二极管。

低电压差分(LVDS):低电压差分信号。

国家电视系统委员会(ntsc): ntsc标准，国家电视系统委员会标准

屏幕上显示屏上显示(OSD):

相位交替线(PAL)AL标准(逐行反向)。

印刷电路板(PCB):印刷电路板。

Plasma显示面板(PDP):等离子显示器。

sequential couleur avec memoire(secam): secam标准(顺序和存储彩色电视系统)

超级扭曲向列(STN):秒扭曲方向列的显示类型。

S-videS终端与复合视频信号相比，分离并传输对比度和颜色。

自动连接攻丝(TAB):挠性带。

Tape Carrier Package(TCP):柔性电路板。

瘦薄膜转换器(TFT):薄膜晶体管显示类型。

transition minimized differential signaling(TMDS)

扭转Nematic(TN):扭转栏的显示类型。

vacum fluorescence display(VFD):真空荧光显示器。

视频图形阵列(VGA):视频图形阵列。

按需视频(VOD):视频点播。

有效显示区(Active Area)

液晶屏上的有效显示区域显示文本图形的整个区域。请参见下图。白色区域是此面板的有效标记区域。

开放率(Aperture Ratio)

开口率是每像素光线透射的有效区域除以像素的总面积，开口率越高，整个屏幕越亮。

宽高比(Aspect Ratio)

“纵横比”是屏幕宽度和高度的比率。如果计算机屏幕和普通视频宽高比为4:3高清电视，则提供1633609的宽屏液晶屏幕。

B/M(黑色矩阵):

用于在Color Filter中屏蔽R、G、B Pixel之间的间隙，大大减少LCD光点之间相互干扰造成的光解，提供更稳定、更清晰的图像质量，提高阅读舒适度，减轻长期使用带来的眼睛压力和疲劳感。

冷阴极射线管(CCFL)

Cold Cathode Fluorescent Lamp

如果对荧光灯的两个电极施加高压，电子将从电气极端发射，电子将被高电压加速，与管子内的水银原子碰撞，水银原子碰撞后从不稳定状态迅速恢复稳定状态，将过多的能量释放到紫外线nm。这种释放的紫外线从荧光粉吸收转化为可见光。

C/F(颜色过滤器) (颜色过滤器):

颜色滤镜有有序的RGB(三原色)像素，进入的光可以通过滤镜混合到多种颜色中。

Ltps & lt低温多晶硅& gt

Ltps(低团队)

perature Poly silicon)低温多晶硅，就是在摄氏600oC或更低的温度下经过雷射回火 (Laser anneal)的制程步骤所生产的多晶硅，具有高开口率、可内建驱动IC等外围电路于玻璃基板上、 TFT 反应速度更快且面积缩小、接点数及零件数减少、系统设计简单化，面板可*度提升，以及降低材料成本等优点。
Luminance〈明亮度〉
明亮度指一对象可见亮度。其取决于可反射光之多寡并由一平方公尺(cd/m2)内之多少烛光来衡量其亮度。因表面物质反射属性之多样化，类似的照明度因对象表面反射属性之不同而造成不同的明视度。例如，同样的光源照射于一黑一白的房间，黑色房间之明视度相较于白色房间的明视度是非常低而且昏暗。
Moire一种因LCD面板与背光模块刻痕方向不能匹配所造成的光干涉现象。
Mura
水波纹：指在显示影像时，所产生的画面局部或全面的不均匀现象。
Response Time〈反应时间〉
的是屏幕画素接收到信号后，由白转黑(Tr)及由黑转白(Tf)所需转变时间。所需转变时间是越短越好。较短的反应时间使画面转换更为顺畅。一般而言，其都低于60ms. Response time =Tr+Tf
Resolution of Display
VGA = Video Graphics Array 640xRGBx480 Dot
SVGA = Super Video Graphics Array 800xRGx600 Dot
XGA = Extended Graphics Array 1,024xRGBx768 Dot
SXGA = Super Extended Graphics Array 1,280xRGBx1,024 Dot
SXGA+ = Super Extended Graphics Array + 1,400xRGBx1,050 Dot
UXGA = Ultra Extended Graphics Array 1,600xRGBx1,200Dot
Spacer〈间隔粒子〉 两片玻璃基板间, 均匀洒上的球形树脂粒子, 用来撑出一个间隙, 以灌入液晶, 其作用类似我们盖房子时的柱子。
Uniformity〈均匀度〉
画面的均匀度；将一Panel分为数等份，分别测量其中心点的亮度，所测得的最小值除以最大值即是此Panel均匀度，均匀度越高表示Panel画面越稳定。
View Angle〈视角〉
面对屏幕，往其上、下、左、右四方观测，调整此屏幕直到其无法由此四方看到屏幕画面之角度。以监看者之视觉舒适，可调整视角之广狭。
Back light〈背光源〉
液晶Panel的背面所设置光源。萤光灯管（热阴极管或冷阴极管）、导光板、扩散板所构成。
Contrast Ratio〈对比度〉
此为黑色与白色之间的对比。比值越高，色彩越鲜明。
FPC
Flexible Printed Circuit；可弯曲印刷电路。
Inverter 〈换流器〉
DC/AC换流器主要应用于TFT 面板背光源之power supply。它使用高电压来驱动冷阴极射线管。此独特的电力仪器具有高瓦特数、高效能及坚实小巧的设计。
LVDS
Low Voltage Differential Signaling；数字显示接口，具有高效能、高速与低功率消耗等特色。
Laser Anneal〈雷射回火〉
低温多晶硅与非晶硅最大差异在于，LTPS 的薄膜晶体管TFT，经过雷射回火 (Laser anneal)的制程步骤；利用雷射作为热源，雷射光经过投射系统后，会产生能量均匀分布的光束，投射于非晶硅结构的玻璃基板上，当非晶硅结构玻璃基板吸收雷射的能量后，会转变成为多晶硅结构
QCIF
(Quarter Common Intermediate Format):
QCIF 为视讯会议格式，其每秒可传输30页的资料，每一页有144行、每一行有 176画素(pixel)。 其分辨率为CIF之1/4。QCIF为 ITU H.261 视讯会议之标准。CIF 及QCIF互为兼容并适用于NTSC, PAL 及SECAM三种TV标准。
White Chromaticity 为衡量RGB三原色的均衡值的测量方法。较高之色温产生偏蓝的白色； 较低的色温产生偏红的白色。
A
a-Si
amorphous silicon
以材料结构而言，amorphous的意思是指未结晶的状态。Amorphous silicon膜具有作为半导体材料之特性，可用plasma CVD装置在400℃以下的温度下形成。因此成为使用玻璃基板之主动矩阵（active matrix）方式液晶面板的TFT主力组件材料。
英：
Amorphous means lacking distinct crystalline in material structure’s term. Amorphous silicon film has the quality that can be used as material of semiconductor. It can be formed by using plasma CVD equipment under temperature of 400 degree C. Therefore, it is the major material for manufacturing TFT of LCD panel, which uses glass substrate with active matrix.
a-Si TFT
amorphous Silicon Thin Film Transistor
以amorphous silicon为构成材料之电场效果型的薄膜晶体管。带有source、drain、gate三种电极之3端子组件。最常使用为主动矩阵（active matrix）液晶显示器的开关。
英：
The Field Effect type TFT with amorphous silicon material contains three terminal components of three types of electrodes: source, drain, and gate. They are often used as the switch of active matrix type LCD.
ACF
Anisotropic Conductive Film
英：
异方性导电膜，指含有导电性粒子之热硬化或热可塑性的树脂薄膜。主要用于液晶显示面板与驱动IC之讯号传输连结，需针对不同之接合接口选择适合导电粒子及密度，一般而言用于fine pitch之导电粒子其直径约为3~5 um。
Anisotropic conductive film means the thermosetting or thermal plastic resin film which contains conductivity particle. It is used major in LCD panel, and to drive the signal connection, transmitting in IC. Different interface connection requires specific conductivity particles and density accordingly. Generally speaking, the diameter of conductivity particles, which used for fine pitch, should be three to five um.
Active area
在液晶显示面板中具有显示功能之画素总面积。
英：
In LCD screen, it serves the purpose of showing the total surface area of functional pixels.
Active matrix
在画素或dot上设置主动组件，于写入期间激活主动组件而写入data电压、其它期间则关闭主动组件以维持电压之矩阵驱动方式。依据主动组件的种类区分为3端子型的TFT方式与2端子型的TFD（MIM）方式。2端子型的制造工程可简化。
英：
It sets active components on pixel or dot, witch activate active component to write data voltage during the writing period, and during other period, it shut off active component to maintain voltage of matrix driving method. According to different types of active component, it is divided into either 3-terminal model TFT or 2-terminal model TFD (MIM) methods. The manufacturing process of 2-terminal model can be simplified.
Anti-glare treatment
在液晶面板表面设置凹凸，以降低镜面反射之处理。Anti-glare处理的程度是利用积分球式光线透过率量测方式，以全光线透过率与散乱光透过率的比定义的。
英：
Convex and concave surface is configured on the LCD panel as the treatment to reduce the reflection of mirror. The extent of Anti-glare is to use the measuring method of light penetration of integral sphere model to define the ratio between the rate of full-light penetration and the rate of scatter light
Anti-reflection
在表面上包覆多层折射率不同的膜，用来消除界面的反射光之处理。
英：
It is a treatment to eliminate reflection light from interface surface, by coating many layers of film with different reflecting rate on the surface.
Aperture ratio
单一画素中可透光面积与画素总面积之比值。开口率之大小与TFT所使用之金属导线特性及Cell制程能力有关。
英：
It is the ratio of the luminary surface in a single pixel comparing to the surface of total pixels. The opening rate is determined by the nature of metal interconnect and the capability of Cell manufacturing of TFT.
APR® plate
液状紫外线硬化型树脂凸版。厚度从1.0~3.0都有，种类甚多，为了提供液体的转写效率，在画面部分的表面增加一层网状物。制版时，版系根据版体的直径，事先将画像缩小后制成。因为版即使在萤光灯下也会加促硬化，故保管上必须非常注意。（旭化成工业(株)的登记商标）
英：
There are many kinds of resin projecting plate of UV hardening model in liquid state with a thickness ranging from 1.0 to 3.0; for the purpose of elevating the efficiency of pattern transformation for the liquid, the surface of the picture portion has been mounted a layer of meshed stuff. When perform the plate making, the pattern has been miniaturized and then finished in accordance with the diameter of plate. Since the hardening of plate will be promoted even under fluorescent light, special attention is required for preservation. (Trademark of Asahi Chemical Industrial Co., Ltd ).
Array
指玻璃基板上已配置TFT等switching组件，但未成为Cell前的状态。
英：
It is the state in which the screen has been equipped with TFT switching device, but it is still not a cell yet.
Aspect ratio
显像后的resist膜，或用蚀刻形成于基板上的pattern之深度与宽度的比。Aspect比＝ b/a（a：蚀刻的宽度，b：蚀刻的深度）
英：
It is the ratio between the depth and width of the pattern on the etched substrate or the resist film after pattern is developed. Aspect ratio = b/a (a : etching width, b : etching depth)
COG
Chip On Glass
直接将驱动IC之I/O与显示玻璃基板的电极端子面对面接合之方式，COG模块构装所使用之驱动IC必须先长凸块(bumping)，液晶面板模块构装之凸块材质为Au，目前以ACF为接合材料之制程较成熟。
英：
It is a process of connecting electrode terminal of display glass substrate and I/O of Driving IC directly to each other. The Driving IC must have bumping, and the material used for liquid crystal substrate bumping is Au. The manufacturing process, which uses ACF as its connecting material, is more matured.
COP
Chip On Plastic
直接将IC chip接续在塑料基板的电极端子上之方式，为Chip On Plastic之简称。装设塑料基板液晶面板之driver IC时所使用的。
英：
It is a simplified term of Chip On Plastic, which is a method of connecting IC chip to the electrode terminal of plastic substrate. It is used for setting the driver IC onto the liquid crystal panel of plastic substrate.
Cold cathode fluorescent tube
为Back light其中一种光源，采用金属阴极之萤光灯管。利用高电场引起发光放电，然后用此放电所产生的紫外线激发萤光体而发光之放电灯管。基于发热、寿命之考量，大多采用冷阴极管。
英：
It is one of the light sources used in Back light, and it uses the fluorescent tube of metal cathode. The discharge tube that uses high electrical field to cause glow discharge and the ultra violet light generated from this type of discharge would trigger the fluorescent particle and glow. Considering the heat and life time factors, the cold cathode fluorescent tube is more frequently used.
Contrast ratio
液晶On?uOff时最大辉度与最小辉度之比。液晶依画面视角的不同，其contrast也会跟着改变，因此以最大的对比来表示。通常STN以10：1表示、TFT以100：1表示。
英：
The ratio between the maximum and minimum brightness when the LC is On / Off. The contrast changes with different viewing angles, and therefore, maximum contrast ratio is used for display. Generally, STN is 10:1 and TFT is 100:1 for display.
CD
Critical Dimension
一般是指100um以下的pattern线宽或间隔，为表示pattern位置之尺寸值。使用于露光量、现象条件、蚀刻条件等制程参数，或制品尺寸管理方面。
英：
CD means the gap or width between patterns under 100 um, and it is to show the dimension measurement of location of pattern. It is used as a parameter of light exposure quantity, and etching conditions in manufacturing process or dimension management aspect of products.
Crosstalk
由于画素间信号干涉，使对比高的画面轮廓在背景部产生的拖曳现象。每个画素都设置理想switch的主动矩阵方式不会产生crosstalk。
英：
Due to the signal interferences between pixels, the background would generate dragging phenomenon in high contrast screen. Cross talk can be eliminated by fixing activate matrix type of ideal switch on each pixel.
5楼 主题: RE: 目前最全的液晶专业术语(中英文资料)
飞花似花 发表于2006-05-08 11:51 [回复]
Dark defect
不随信号改变而一直保持低辉度状态的点状缺陷。
英：
Dark defect is a kind of dot form fault that does not change with signals and keeps in low BRIL status.
Data line
FT基板中传达显示信号之垂直方向的配线。因为接续在各画素TFT的Source电极或Drain 电极上，故又称为Source线或Drain线。线宽通常为数um到10um不等。
英：
It is the perpendicular wiring used in TFT substrate to transfer display signals. Because it is connected with the Source electrode or Drain electrode on each pixel in TFT, it is also known as Source line or Drain line. The width of the line is often between few um to 10 um.
Dichroic Mirror
仅选择在特定的波长区域内的光来做反射的光学镜。一般是利用层积的多层膜的光之干涉经由反射而取出各式各样的颜色的光。使用在投写型的投影机上。
英：
It is a kind of optical mirror that only reflects certain light in some chosen light spectrum. Normally, many layers of film to interfere with light and with reflection to generate various color of light. It is applied to projectors with poly-silicon LCD.
Dot
构成各画素的要素点（显示的最小构成点）。
英：
Dot is the point that constructs each pixel. (the smallest display unit)
Driver IC
驱动液晶面板的回路或IC。Matrix显示有扫描电极（行电极）Driver与信号电极（列电极）Driver二种。由QFP变迁为TCP。多硅晶（poly-silicon）的面板则是直接将Driver IC形成在显示面板中。
英：
It is the IC that drives the LCD. There two types of display matrix: Scanning electrode (column electrode) Driver and Signal electrode (row electrode) Driver. The package of driver changes from QFP to TCP. The Driver IC of poly-silicon LCD panel forms directly in the display screen.
Dual Scan
将液晶面板的配线自上下两端开始接续的方法。
英：
It is a method of connecting continuously from top and bottom wiring in the LCD.
E
EWS
engineering workstation
拥有color graphic display与高度演算能力，技术者为了能互动地执行LSI或electronics system之开发、设计所用的计算机。透过计算机网络与其它EWS相互接续而达到设计Data共有化，以构筑效率良好的分散设计环境。
英：
It is a computer designed for high color graphic display calculation, and it is used for execute LSI interactively or for electronics system development. Through network, it can connect to other EWS to achieve data sharing designing, hence, better and efficient distributed deigning environment are built.
F
Flatness
大多指heat head与支撑台的平行度。热压着时，每个tool相互间的关系比平行度重要。
英：
Most of the time, Flatness means the parallelism between the heat tool and support platform. When there is heat, the relationships between each tool is more important than the parallelism.
Flicker
画面辉度之周期性变动。也称为闪烁。出现Cross Talk较多的画面其Flicker也会较明显。其起因与Crosstalk相同。
英：
Flicker is a periodic change of the brightness of the screen. Flicker is more obvious when there are more cross talk, and the cause of flicker is the same as Crosstalk.
FPC
Flexible Printed Circuit
可挠曲印刷配线板。使用于实装有液晶driver IC的印刷基板与COG基板等界面上之配线板。
英：
FPC means flexible printed circuit board. FPC is the circuit that applies to printing circuit with LC driver IC and COG circuit interface.
FCA
Flip Chip Attachment
为face down bonding其中一种。指将LSI chip上的接续电极直接接续在基板或package的配线用电极上。一般是在LSI chip上形成焊锡bump与基板接续，但COG则是使用导电paste、ACF等来接续bump与基板。
英：
FCA is one type of the face down bonding. It means attaching the connecting electrode of LSI chip directly to the circuit or wiring electrode of package. Generally, LSI chip forms the soldering bump and attach to the circuit, but COG uses conductivity paste, or ACF for attachment between bump and circuit.
FLCD
Ferroelectric Liquid Crystal Display
指强诱电性液晶。材料使用sematic液晶，属于单纯matrix 方式，可做高速应答。虽然使用在大型panel上价格较便宜，但另一方面，由于很难做安定的配向，故在画面的要求上有其困难之处。
英：
It uses sematic LC as its material, which belongs to simple matrix type, and has high speed response. Although it is cheaper to apply on large type panel, but on the other hand, it is very hard to achieve stability. Therefore, it is difficult to achieve quality of the screen.
Folding TCP
将实装后的TCP折弯一次或二次之形态的TCP。有助于面板边框area之狭小化。
英：
Folding TCP is formed by folding the fixed TCP once or twice, and it helps to minimise the frame area of circuit
GPS
以美国24个卫星传来的时间与位置等情报为基准而知道现在位置的方法。将这个情报与地图情报搭配使用的方法即可汽车导航系统。
英：
Global Positioning System allows users to find out the time, and exact current location through 24 different satellites. Applying this system and map information achieves the vehicle navigation system.
Gray scale
指介于最大辉度与最小辉度之间的中间调显示。数字信号输入时，与2, 3, 4, 6, 8 bit相对应的有4, 8, 16, 64, 256阶调。模拟信号输入则可作无限阶调之显示。阶调显示的方式分为液晶驱动电压变化及frame间的时间调节。
英：
Gray scale is for tuning the display between maximum and minimum brightness. When digital signal is input to it, according to 2, 3, 4, 6 and 8 bit, there are 4, 8, 16, 64 and 256 different gray levels. Analogue input can be used for infinity level tuning display. There are two ways of gray scale: LC driving voltage tuning and frame rate control.
I
ILB
Inner Lead Bonding
内引脚接合，指驱动IC之bump与Poly-imide tape上之Cu lead以Eutectic Bonding方式接合之制程。
英：
ILB bonding is a manufacturing process which attach the bump of Driver IC to the Cu lead on poly-imide tape with Eutectic Bonding method.
Image sticking
经过长时间显示同一pattern后，切换至其它显示时，前面的pattern会长时间残留的现象。
英：
After a long displaying time of the same color pattern, the color pattern would stay on the screen over a period of time, once switched to other color display.
Interconnection pitch
指接续pad或bump间的pitch。未必与画素pitch一致。使用面bump LSI时，接续pad可比画素pitch大。
英：
Interconnection pitch is the pitch connects pads or bumps, and it is not necessary to be the same as the pixel pitch. When using the bump LSI, the pad pitch can be larger than the pixel pitch.
Interlace
将1个frame分成奇数号扫描及偶数号扫描这二种区域，使这二种区域交替驱动之方式。可抑制闪烁。主要使用于电视显示方面。计算机则以non-interlace驱动为主。
英：
To split a frame into two areas with odd and even scanning lines. By allowing these two areas to switch driving modes between each other, flickering can be reduced. This is mainly used in traditional television sets. Computer monitors mostly use non-interlace mode.
Inverted staggered structure TFT
Gate电极配置于下部（bottom gate）之stagger构造的TFT。可在真空中连续形成gate绝缘膜及半导体层，因为易于使MOS界面清净化等理由，为多数的a-Si TFT所采用。
英：
It is a type of TFT that has Gate electrode fixed to the stagger of bottom gate. The gate insulated film and semi conductor layer can be formed in vacuum status. It is mostly applied to a-Si TFT because it is easier to purify MOS interface with it.
Inverter
将B?uL光源（萤光灯或EC）以高周波点亮的点灯回路。
英：
It is a lighting circuit that lights the radiofrequency with B / L light source (florescent lamp or EC)
K
KGD
Known Good Die
Known good die之简称。指经确认为良品之LSI chip。在chip level中受品质保证，但成本较高。
英：
KGD is a high quality LSI chip, and it has quality guarantee in its chip level and cost more.
L
LCD
Liquid Crystal Display
液晶显示器。利用偏极化光及液晶分子之特有光电特性，以电压控制画素之亮及暗，达到影像明暗对比之效果。
英：
LCD utilizes the polarization light and special light and electrical property of LC molecule to control the darkness and lightness of pixel with voltage. Hence, to achieve the effect of contrast between bright and dark.
LCD Controller
供给Driver回路（IC）上必要的timing信号等控制信号的回路（IC）。
英：
LCD controller supplies the necessary timing signal for Driver IC and other signal controlling IC.
LCD Driver
指驱动液晶panel的回路或IC。以matrix来表示，可分为行电极Driver与列电极Driver
英：
LCD Driver is for driving LC panel circuit or IC. In matrix terms, it can be differentiated into column electrode Driver and row electrode Driver.
LCD Projector
将小型的液晶面板（LCD panel）放大投影而取得大画面之方式。可分为使用3片单色TFT的3板式及使用1片彩色TFT的单板式。从价格、重量来看，单板式较有利。3板式系利用二色镜（dichroic mirror）自光源的光中取出光的三原色后进行彩色之显示。分为rear pro 与 front pro二种方式。就亮度来说，rear pro较有利。
英：
A method to magnify and project a smaller-sized LCD panel into a bigger display. This can be achieved by using either three single-color TFT or one color TFT. From a price and weight standpoint, it should be more beneficial to use the one color TFT method. The three single-color TFT method uses a dichroic mirror to display the colors from external light sources. It is divided into rear projector and front projector. In terms of brightness, rear projector has more advantages than front projector.
Line defect
出现于水平及垂直之线状的显示缺陷。
英：
Line defect is a display defect which appears in horizontal or vertical lines.
Luminance
画面的明亮度。单位为cd/m2。 在透过型TFT彩色液晶上则是指液晶面板的透过率与B/L辉度之积
英：
It’s the luminance of the screen, and unit of measure is cd/m2. In TFT Color LC terms, it is the product of light through rate and B/L brightness.
MA
Module Assembly)
将panel、PCB、bezel等零件组装起来成为液晶Module的工程。
英：
Module Assembly engineering is to assemble panel, PCB, bezel and other parts to a LC module
MIM
Metal Insulator Metal
用2片具有非线形抵抗性之薄绝缘体的金属膜挟住的2端子组件。绝缘体一般采用TaOx。使用为主动矩阵液晶显示器之开关。
英：
MIM is a component that uses 2 piece of nonlinear resistance thin insulated metal film to hold 2 terminals. TaOx is often used as the insulator and function as the switch of active matrix LCD.
Mother glass
母玻璃基板，TFT使用无碱玻璃（为防止碱离子对于TFT的污染）；C-ST(N) 使用碳酸钠石灰玻璃（普通玻璃）。又称为可作多面取前的大块玻璃，目前TFT-LCD厂之世代即是以Mother Glass大小区分
英：
TFT uses alkali-free glass (to prevent pollution from alkaline ion to TFT); Color STN uses natronite lime glass (normal glass). It is also known as glass in large size for poly-facet processing., the generation of current TFT-LCD factories generation are differentiated by the size of Mother Glass.
MLS Drive Multi Line Selection Drive
由OPTLEX所开发之一种能使C-ST（N）的contrast比提升的技术。利用同时选择及驱动复数的线以实现高速应答与高对比。
英：
A development process derived from OPTLEX which utilizes the C-ST (N) process. At the same time, it selects and drives multiple lines to enable a high-speed response and contrast
Mura
辉度色度某部份不均匀的现象。色度不均匀的现象称为色Mura。
英：
Mura is a phenomenon when the BRIL and color rate are not even, and uneven color rate is known as Mura color.
Mushroom bump
断面形状像茸状的bump。镀层电镀得比电镀光阻的厚度高而形成的。
英：
The cross-section of bump is like mushroom, and it is formed when the electroplating plate thickness is higher than the photo resister.
N
ND filter
Neutral Density filter
不管波长为何，为了以一定的比率减弱光的强度以得到适当的光量所使用的滤光器，是一种不会改变光束的大小，但可以减少光量的滤光器。分为全面均一浓度的个别type及能针对角度表示线状浓度变化的圆形type二种。装置于检查装置内的CCD camera前部，其目的是使DUT image的明亮度达到最适化。
英：
The light filter device that works regardless of the light spectrum, and will reduce the light according to certain ratio to obtain suitable amount of light. It does not change the size of the light beam, but to decrease the quantity of light. It is differentiated into 2 types: one type is to even the density of whole surface and another round shaped type which varies the light density according to different angle. It is fixed to the front part of a checking device, CCD camera, which is used to adjust the luminance of DUT image to the most suitable status.
Non interlace
将画面的一个Frame从上面一条一条线的依顺序扫描来表示的驱动方式。个人计算机用的Monitor是其代表。
英：
Non interlace is a driving method, which used widely in PC’s monitor, scans line by line accordingly.
NTSC
National Television System Committe
电视机信号的标准方式之一。以美国、日本为中心而被使用。扫描线数525条，每秒使用30 Frame，为减低Flicker而分为偶数?u奇数 filter来扫描。
英：
NTSC is one of the standard TV signal that used mostly in America and Japan. It scans 525 lines, and 30 frames in a second. In order to reduce flicker, it is scanned with even / odd number filter.
O
OLB
Outer Lead Bonding
Tape bonding时，自inner bonding完成的tape上切取已连接die的outer lead部分，堆栈在package或基板的电极上，然后以加热及加压的方式将之接合的装置。此种接合方式称为outer lead bonding。
英：
During Tape bonding, by cutting the outer lead part from the die which is connected to the tape formed from inner bonding, and then adding heat and pressure to complete the attachment. This type of attachment is called out lead bonding.
P
PAL
电视机信号的标准方式之一。以欧洲、东南亚为中心而被使用。扫描线数625条，每秒使用25 frame，与NTSC一样分为偶数?u奇数filter来扫描。
英：
PAL is one of the standard TV signals that used mostly in Europe and South East Asia. It scans 625 lines, and 25 frames in a second. Like NTSC, it is scanned with even / odd number filter.
Passive matrix
各画素上没有主动组件，扫描电极与data电极的交*部对应到画素或dot上，然后直接印加驱动信号的矩阵方式。显示类型有TN、STN等，主要采multi-plex驱动。一般是指将common及segment的电极形成于各位的玻璃基板上，使这些电极交*并将液晶包在这些电极之间的形式。
英：
There is no active components on each pixel, the grid matrix activates the driving signal directly by scanning the cross part of electrode and data electrode to the according pixel or dot. Forming the common and segment electrode on individual glass substrate, the Passive matrix is constructed by wrapping the electrode crosses within LC.
PEP
Photo Etching Process
使用感光光阻，仅就必要的厚度来蚀刻特定的场所以得到希望的配线的方法。
英：
PEP uses photo resistive sensor to obtain expected wiring with necessary thickness in specific etching environment
Pitch
指光罩上规则配列的pattern中，任意2个量测pattern中心点的距离。
英：
It is the distance between the center of any 2 measured pattern, which is in a regular shape in the photo mask.
Pixel defect
在TFT等active方式上出现之以画素为单位的显示缺陷，其代表性的缺陷是在黑显示时光线被遮住而成白缺陷或相反地成黑缺陷、以及平时点灯时的辉点缺陷等。形成原因有TFT的动作不良或者异物、接触不良等等各种原因。很难明确地指出其原因。
英：
It is a displaying defect of pixel unit which shows on active type of TFT. The property of such defect is when the light is blocked and shows white defect while displaying black color and vice versa.
Poly-si TFT
Poly-silicon Thin Film Transistor
以多结晶（poly silicon）为构成材料之薄膜晶体管。电荷移动度大约比非结晶硅（amorphous silicon）大一位数，因为可小型化，故主要使用于投射型面板上。
英：
The mobility of charge is approximately one order faster than amorphous silicon, so it can be made into small size. Therefore, it is widely applied to projector type screen.
Post bonding
利用治具透过TCP对ACF层作加热及加压，使ACF胶材聚合反应率达90%u以上，以增加TCP与面板之连接强度并作导通。
英：
By using bonding equipment to add heat and pressures to TCP and ACF layers, and make the cross-linking rate of ACF material to 90% and above. Hence, it increases the bonding and conductivity between TCP and circuit board
PPI
Pixel Per Inch
指在Active Area对角线上单位英?妓?具有之画素数目，用以表示画面之分辨率。
英：
The total amount of pixels of active areas on diagonal lines with inch unit, which shows the resolution of screen.
PWB
Printed Wiring Board
将连接回路零件的电气配线依适当的方法在绝缘物上以电气导体再现。一般指上面没有零件的电路板。
英：
By using appropriate method on the electrical wiring of circuit connecting parts, to show the electrical conductor on insulating material. It normally means the circuit board without parts on it.
Pre-bonding
透过ACF将TCP以高精度定位于LCD面板上，然后利用ACF的半硬化性，以低温热压着进行预先接合之工程，假压着制程导入有助于高分辨率模块量产设计。
英：
By locating ACF and TCP on LCD with high accuracy, and with the half curing of ACF, to proceed the bonding process with low temperature press. Low temperature pressing is helpful for mass production of high resolution module design.
Pulse heat
电阻加热方式的加热治具。加入瞬间大电流，一口气由常温上升至作业温度的方式。治具的热容量小，切断电流即可快速使温度下降，故可维持运转，直接在加压状态下回复至常温。温度的均一性比constant heat方式的治具差。
英：
Resistor heating type bonding equipment allows large amount of electric current flow and can instantly increase the heat from normal temperature to manufacturing temperature. The bonding equipment has small heat capacity and can lower its temperature by cutting off electric current. Hence can maintain its running, and recover to normal temperature under pressure status. The temperature uniformity of it is worse than the constant heat type of bonding equipment
Resin BM
以含有黑色着色剂的树脂材料形成之BM。一般是采用遮旋光性能高的carbon black作为着色剂。感旋光性树脂材料以acrylic系列为代表，非感旋光性树脂材料以poly-imido系列为代表。通常用photolithography法形成BM pattern。树脂BM反射低且成本低，但遮旋光性能不及chrome。
英：
Resin BM is made of resin material with black artificial color, and the artificial color often uses carbon black color which has good quality at blocking light. Acrylic series products are the representative of phototonus resin material, and poly-imido is the representative of non phototonus resin material. The BM pattern is normally formed with photolithography method. Resin BM has low capital cost and low reflection, but the light blocking property is not as good as chrome.
Resolution
画像细致度的指针。液晶显示器的分辨率取决于画素的pixel。
英：
It is the index of the screen resolution fineness. The resolution of LCD is determined by the amount of pixels
Rubbing angle
工作基板基准面与rubbing reel之间的角度。Rubbing的角度决定了视角的方向。
英：
It is the angle between the datum plane of the working substrate board and rubbing reel, and Rubbing angle determines the direction of the viewing angle.
Rubbing cloth
配向处理时使用的植毛布。将植毛布缠绕在rubbing reel上后使其旋转，擦拭配向膜。
英：
It is the rubbing cloth used for orientation processing. Wind the rubbing cloth around the rubbing reel, and then make it whirl to rub the orientation film.
S
Scanning line
TFT基板中传达信号至gate电极上之横方向的配线。又称为gate线，具有选择水平方向某画素行的功能。连接到被选取的扫描线上之各画素的TFT成导通状态，Data线的显示信号得以写入各画素内。扫描线内的信号延迟会对画质产生重大影响，因此必须是延迟少的低电阻扫描线。
英：
It is the horizontal wiring line, which transfers signal to the gate electrode in TFT board, it is also known as gate line. It also has the function to select horizontal pixels. When the pixels are selected by the scanning line, the TFT is in a conductivity status, and signals can be written into each pixel from Data line. The signal delay in the scanning line causes great impact to the quality of the screen image, and therefore, low resistor scanning line should be used.
Scratch
Color filter的外观缺陷之一。指color filter表面上的细微伤痕，大多是基板处理时机械性接触所造成的。
英：
It is one of the defects from the outside view of color filter. It means the tiny scar on the surface of color filter. Most of the time, it is caused by mechanical contact during circuit board treatment.
Seal width
将2片液晶面板的基板接合并固定之seal部的宽度。就械械性强度或信赖性而言，某种程度的宽度是必要的，但若要扩大显示部的有效面积或确保安装的区域，则宽度最好窄一点。
英：
It is the width of the seal, which used to connect two pieces of LC circuit. Regarded to the mechanical toughness and reliability, certain seal width is necessary. However, in order to enlarge the active screen display area or to secure the fitting area, the width should be narrower.
Separate film
挟在ACF tape层之间的薄膜。
英：
It is the film fitted in between the layers of ACF tape.
Slim TCP
输入lead与输出lead之间的间隔较窄之TCP。有助于面板边框范围之狭小化。
英：
It is a TCP with narrower gap between input lead and output lead, and this helps to narrow the size of frame area of the circuit board.
Spacer
为了使液晶面板（cell）中液晶层的厚度均一而放入上下基板间之均一直径的物体。Spacer的材料有plastic beads或玻璃纤维。依Cell gap不同，使用的spacer直径（2~6 m）种类甚多，Spacer有ball spacer与photo spacer之区别。
英：
It is a object with same diameter fitted in between top and bottom glass substrate, its purpose is to ensure the same thickness of LC layers in the cell of LC substrate. According to different Cell gap, the diameter of spacer varies from 2 to 6 um. There are various types of spacer, and it is differentiated into ball spacer and photo spacer.
Staggered structure TFT
TFT的构造依晶体管构成要素的配置方法大致区分为stagger型与coplanar型。前者指的是在gate电极?ugate绝缘膜与source?udrain电极之间配置半导体。后者指的是在gate电极?ugate绝缘膜与半导体之间配置source?udrain电极。另外还衍生出gate电极是在TFT上部（top gate）或下部（bottom gate）的类型。顺stagger构造是gate电极配置于上部之stagger构造，使用于部份的a-Si TFT LlCD上。
英：
TFT structure is divided into stagger type and coplanar type according to the ways the transistors are constructed. Stagger type means the semiconductor is fixed in between gate electrode / gate insulating film and source / drain electrode. Coplanar type means the source / drain electrode is fixed in between gate electrode / gate insulating film and transistor. There is also another TFT types which fits the gate electrode on either top gate or bottom gate of the TFT. When the gate electrode is fitted to the stagger on top gate, it is known as Staggered structure TFT, and it is applied partially to a-Si TFT LCD.
Step coverage
薄膜形成时在薄膜表面的细微段差部上作成之膜的被着状态。段差部上的被着状态直接影响到配线的断线不良等，成为制品良率、品质低下的主因。
英：
It means another film is formed on the micro gaps on the film surface, when the film is produced. Step coverage directly affects quality of wiring, and hence is the major cause of low quality and defect rate of finishing product.
STN
Super Twisted Nematic
具有扭转约180度~270度构造的nematic液晶或采用namatic液晶的显示类型。以一定角度射入到液晶分子轴上的直线偏光由于双折射性的缘故而变调成椭圆偏光。利用电场的有无将液晶分子控制在STN构造与垂直配向之间，即可用双折射性的变调加以驱动。黄色或蓝色是较普遍的，采用特殊的位相膜或补偿液晶板作白色显示，也可以应用于彩色显示上。与TN相比其视角较广，但缺点是应答速度慢。
英：
STN has nematic LC which can twist from 180 degrees to 270 degrees or uses namatic LC display type. With a fixed angle, the straight polarizer shoots on to the axis of the LC molecule and because of the birefringence property, the straight polarizer becomes ellipse polarizer. By utilizing the existence of electrical field to control the LC molecule to stay in between the STN structure and vertical orientation, STN can be drove from the property of birefringence. Generally, they are in either yellow or blue color, and it can display white color when special phase film or compensated LC board. This also applies to color display. Comparing with TN, it has a wider viewing angle, but the disadvantage is slow in response speed.
